Studiomaster DigiLive 16RS Digital Rack Mixer
Availability:In stock
SKU
130003
£869.00
Check your eligibility Fast check - won't affect your credit rating.
Seen it cheaper? We aim to match authorised UK dealers
Quick overview
The Studiomaster DigiLive 16RS is a digital rack mixer and combines the best of both worlds, providing a hybrid mixing system (tablet control or hands-on option). This is the ideal combination of compactness and functionality. 16 inputs, 16 buses, and all the capabilities you would expect from a professional mixing solution.
- See full product description
The Studiomaster DigiLive 16RS is the 19" version of the DigiLive 16. It is a digital rack mixer and combines the best of both worlds, providing a hybrid mixing system (tablet control or hands-on option). This is the ideal combination of compactness and functionality. 16 inputs, 16 buses, and all the capabilities you would expect from a professional mixing solution.
The Studiomaster Digilive 16RS Digital Rack Mixer combines Studiomaster's expertise in live signal processing with cutting-edge technology to provide a simple and versatile mixing console suitable for any live or installation application.
The Studiomaster Digilive 16RS has 16 inputs and 16 internal buses, including 12 microphone inputs with digital gain control, 8 assignable ''smart'' outputs, and numerous digital outputs. The Digilive 16RS mixer, which can be controlled via the onboard 7" touchscreen display or Wi-Fi using an iOS tablet, offers an intuitive and hands-on mixing experience with complete control over every component of your sound.
- 16 input with 16 internal busses
- 12 digital gain mic input channels
- 2 stereo inputs
- 8 configurable smart outputs
- high resolution touch screen
- Ultra compact unit size
- Advanced hybrid user interface
- Full iOS Tablet control
- Mic Inputs: 12 (8x XLR / 4x Combo XLR)
- Stereo Inputs: 2
- Master Output: 2 (Left/Right balanced XLR)
- Smart Outputs: 6 (assignable balanced XLR)
- Internal busses: 16
- Stage monitor: 1 TRS Jack output
- Headphone: 1 TRS Jack output
- Screen: 7″ high definition touch screen
- Operation system: Android system
- Network: Yes, via included WiFi module
- Remote control: iPad iOS via ‘Digilive Blackbox’ app
- Sample Frequency: 48 KHz
- AD/DA: 192 KHz, 24-bit
- DSP: 40 bit float point, SHARC processor
- Effects: up to 8 assignable effect modules
- AES/EBU: Output XLR
- S/PDIF: Input / Output (RCA Phono)
- USB Interface: 2 for playback/recording, scene/setting storage and system updates
- Power Supply: 90-240V ~ 50/60Hz IEC power supply
