Yamaha MG10X CV Analog Mixer
Availability:In stock
SKU
MG10X
£229.00
Seen it cheaper? We aim to match authorised UK dealers
Quick overview
The Yamaha MG10X CV is a top-tier analog mixer with ten channels, ideal for professionals who demand the best possible sound quality. Its preamps are exceptionally clean, and its effects section is comprehensive, which means that it's perfect for those who don't want to rely on USB connectivity or computer setups. This mixer is an excellent choice for anyone who requires flexible audio routing with pristine quality, and it offers the same amazing effects section as Yamaha's renowned SPX effects processors.
- See full product description
The Yamaha MG10X CV is a top-tier analog mixer with ten channels, ideal for professionals who demand the best possible sound quality. Its preamps are exceptionally clean, and its effects section is comprehensive, which means that it's perfect for those who don't want to rely on USB connectivity or computer setups. This mixer is an excellent choice for anyone who requires flexible audio routing with pristine quality, and it offers the same amazing effects section as Yamaha's renowned SPX effects processors.
The MG10X CV has four mono channels with Yamaha's clean, rich preamps, a three-band EQ, and a one-knob compressor. These channels are designed to accept XLR or quarter-inch jack connectors, providing you with the versatility you need. It also has three sets of stereo channels with high and low EQ shelves and stereo RCA inputs, making it easy to connect to other external audio devices. With ten channels of highly flexible audio, the MG10X CV is perfect for compact, all-in-one live mixing, conferences, events, and installations.
So, if you're looking for a mixer that combines clean preamps, a comprehensive effects section, and flexible audio routing, look no further than the Yamaha MG10X CV.
Included In The Box
- 1 x Yamaha MG10X CV Analog Mixer
- 1 x AC Adapter
- 1 x Owner's Manual
- 1 x Technical Specifications Sheet
Features
- Discrete Class-A mic preamps
- High quality sound op-amp
- Switchable phantom power & PAD switch
- 1-knob compressors
- AUX input
- EQ & high-pass filters
- Variety of input & output connectors
- LED level metering
- Built-in SPX digital effects
- Heavy-duty metal chassis
- On-Board Processors: SPX Algorithm: 24 Programs, Parameter Control: 1, Foot Switch: 1 (FX RTN CH on/off)
- Phantom Power: +48V
- Input Channels
- Mono (Mic/Line): 4
- Stereo (Line): 3
- Output Channels
- Stereo Out: 2
- Monitor Out: 1
- Phones: 1
- AUX Send: 1
- Bus: Stereo: 1, AUF[FX]: 1
- Input Channel Function
- PAD: 26 dB (Mono)
- HPF: 80Hz, 12dB/oct (Mono)
- COMP
- 1-Knob Compressor Threshold: +22dBu to -8dBu
- Ratio: 1:1 to 4:1
- Output Level: 0 dB to 7 dB
- Attack Time: Approx 25 msec
- Release Time: Approx 300 msec
- EQ High: (Mono) Gain: +15dB/-15dB, Frequency: 10kHz Shelving
- EQ Mid: Gain: +15dB/-15dB, Frequency: 2.5kHz Peaking
- EQ Low: (Mono) Gain: +15dB/-15dB, Frequency: 100Hz Shelving
- Peak LED: LED Turns On When Post EQ Signal Reaches 3dB Below Clipping
- Level Metre: 2 x 7 -Segment LED Metre (Peak, +10, +6, 0, -6, -10, -20dB)
- Total Harmonic Distortion: 0.02 @ +14dBu, Gain Knob: Min, 0.003 @ +24dBu, Gain Knob: Min
- Frequency Response: +0.5dB/-1.0dB, Refer To Nominal Output Level
- Hum & Noise Level
- Equivalent Input Noise: -128 dBu (Mono Input Channel, Rs: 150Ω, Gain Knob: Max)
- Residual Output Noise: -102 dBu (Stereo Out, Stereo Level Knob: Min)
- Crosstalk: -83 dB
- Power Requirements: PA-10 (AC 38 VCT, 0.62A, Cable Length = 3.6m)
- Power Consumption: 22.9W
- Dimensions
- Height: 71 mm
- Width: 244 mm
- Depth: 294 mm
- Net Weight: 2.1 kg
- Operating Temperature: 0 to +40°
