Pioneer RM-05 Professional Active Studio Monitor (Ex-Display)
Availability:In stock
SKU
RM-05-Ex-Display
Special Price £399.00 Was: £499.00 Save £100.00
Seen it cheaper? We aim to match authorised UK dealers
Quick overview
The Pioneer RM-05 is a professional studio monitor with a HD-Coaxial driver unit for precise point source monitoring. The RM-05 active studio monitor is packed with pro-audio technology as Pioneer DJ have newly developed a waveguide that minimises any unwanted interference between the drivers, to produce a true, neutral sound with exceptional isolation, ideal for near-field monitoring in a professional studio. (Price Each)
- See full product description
The RM-05 Active Studio Monitor inherits its pro-grade HD-coaxial driver unit from the highly respected Pioneer sub-brand TAD, placing the tweeter and the woofer on the same axis to ensure a more accurate response across the high, mid and low range frequencies. The RM-05 active studio monitors are packed with pro-audio technology as Pioneer DJ have newly developed a waveguide that minimises any unwanted interference between the drivers, to produce high SPL and true, crystal clear neutral sound with exceptional isolation, making the Pioneer RM-05 the ideal near-field monitor for any professional studio.
The Pioneer RM-05 Speakers are made from rigid die-cast aluminium cabinets that are skillfully designed to look and sound excellent, featuring curved contours to eliminate resonance, and pa propriety acoustic tube to reduce the standing waves and guaranty the quality of the low to mid ranges. The RM Series also boasts a three band EQ with multiple inputs, giving producers the ultimate flexibility and simplicity in any studio environment.
| Pioneer RM-05: HD-Coaxial driver unit for precise point source monitoring: |
| The Pioneer RM-05 Professional Active Studio Monitor inherits its pro-grade HD-coaxial driver unit from the highly respected Pioneer sub-brand TAD, placing the tweeter and the woofer on the same axis to ensure a more accurate response across the high, mid and low range frequencies. The RM-05 active studio monitors are packed with pro-audio technology as Pioneer DJ have newly developed a waveguide that minimises any unwanted interference between the drivers, to produce a true, neutral sound with exceptional isolation, ideal for near-field monitoring in a professional studio. |
| Pioneer RM-05 Studio Monitors have 50 kHz tweeter for precise, electrifying high frequencies: |
| The Pioneer RM-05 studio speakers have exceptional 1.5-inch hard dome aluminium tweeters that were expertly designed using unique Pioneer technology for additional frequency response. The diaphragm’s shape and materials are optimised to deliver extremely accurate, rousing high frequency sounds. |
| Rigid die-cast aluminium cabinet with curved contours for superb sound clarity: |
| The RM Series cabinets are made from die-cast aluminium for maximum rigidity and to reduce resonance at all volumes. The cabinets have a curved surface to optimise the rigidity and reduce external diffraction whilst give the speaker a sleek design that will look excellent in any studio. |
| AFAST acoustic tube considerably reduces standing waves for clean low and mid frequencies: |
| Pioneer’s patented AFAST*3 technology considerably reduces standing waves that can cause all sorts of problems, as they create a muffled response in the low to mid ranges. An specially designed acoustic tube in the cabinet ingeniously absorbs just the standing waves, ensuring true reproduction of low to mid frequencies. |
| Front-loaded bass reflex system with grooves for smooth, clean bass: |
| The Pioneer RM-05 active studio monitors feature aramid fibre woofers for a strong, ultra robust bass response. Also the front loaded bass reflex design and innovative grooves on the bass ducts help reduce air friction, even when the speakers are positioned against the wall |
| Low/Mid/High EQ settings for added flexibility and control: |
| A three-band EQ (Low/Mid/High) gives producers the option to tailor the monitor speakers’ sound or audition tracks for certain scenarios, and has four pre-sets for each band. |
Other features:
- Auto standby On/Off function
- Wide range of inputs (XLR and RCA)
- Clip indicator to protect the unit from excessive input
- Exclusive toroidal transformer power source for excellent S/N ratio and no distortion
- Custom-designed Class AB bi-amps ensure balance across the frequencies
Specification of Pioneer RM-07 and RM-05
| Pioneer RM-07 | Pioneer RM-05 | ||
| Type | Bi-amp 2-way active speaker | ||
| Enclosure | Bass reflex/Aluminium die-cast | ||
| Tweeter | 1.5-inch hard dome aluminium HSDOM Tweeter | ||
| Woofer | 6.5-inch aramid fibre woofer | 5-inch aramid fibre woofer | |
| Frequency Response（-10dB） | 40 Hz～50 kHz | 45 Hz～50 kHz | |
| Maximum Sound Pressure Level | 109 dB SPL (peak @ 1 m) | 104 dB SPL (peak @ 1 m) | |
| Amplifier output (rated output) | Class A/B bi-amp 100 W LF： 100 W / 4Ω HF： 50 W / 4Ω |
Class A/B bi-amp 100 W LF： 50 W / 4Ω HF： 50 W / 4Ω |
|
| Input ports | Balanced input XLR×1 | ||
| Unbalanced input RCA×1 | |||
| Input impedance | 10 kΩ | ||
| Input Sensitivity | -40 dB ～ +6 dB | ||
| High EQ | -2 / -1 / 0 / +1 dB at 10 kHz | ||
| Mid EQ | -4 / -2 / -1 / 0 dB at 140 Hz | ||
| Low EQ | -4 / -2 / 0 / +2 dB at 50 Hz | ||
| Cross Over Frequency | 1.6 kHz | 1.7 kHz | |
| Power consumption | 195 W | 142 W | |
| Power consumption during standby mode | 0.3 W or less | ||
| External dimensions（W×H×D） | 244 x 337 x 260 mm | 203 x 281 x 225 mm | |
| Weight | 12.3 kg | 9.3 kg | |
| Accessories included | Power cord, Operating instructions, Rubber leg, Bottom cushion | ||
